Case Study 2 — Internal Knowledge Assistant (RAG)

A hands-on FDE case study: turn 5,000 scattered company documents into an AI assistant employees can actually ask questions — using embeddings, a vector database, and RAG.

Table of Contents

• The Problem
• Discovery: Auditing the Documents
• Solution Design: How RAG Works
• Step 1 — Extraction
• Step 2 — Chunking
• Step 3 — Embeddings
• Step 4 — Storing in a Vector Database
• Step 5 — Retrieval-Augmented Generation
• Evaluating the Assistant
• Full Ingestion Pipeline
• Keeping the Index Fresh
• Handling Permissions and Confidential Docs
• Project Timeline and Cost
• Failure Modes and Fixes

The Problem

A 300-person company stores policies, HR docs, engineering runbooks, and product specs across Google Drive, Confluence, Notion, and email attachments.

Employees spend 30+ minutes hunting for answers like "How many vacation days do I have after 2 years?" HR answers the same onboarding questions every week. Knowledge exists — it's just unfindable.

The fix: an internal chat assistant that answers from company documents only, with citations.

Discovery: Auditing the Documents

Before any code, answer these questions:

1. Where does knowledge live? Map every source: Confluence spaces, Drive folders, shared inboxes.
2. What is the "hot" content? Ask HR/support leads which 50 documents get requested most. Index those first.
3. What's confidential? Salary bands, legal docs, and personal records usually must be excluded or permission-gated.
4. Who owns each source? You'll need their help keeping documents fresh.

Note: A RAG assistant is only as good as the documents behind it. In practice, cleaning up 20 badly-written core documents beats ingesting 5,000 messy ones.

Solution Design: How RAG Works

RAG (Retrieval-Augmented Generation) = find the relevant documents first, then let the LLM answer using them.

Company documents ──► chunk ──► embed ──► vector DB
                                          │
User question ──► embed ──► similarity search ──► top 5 chunks
                                          │
                            LLM prompt = question + chunks ──► answer + citations

Why not just dump all documents into the LLM prompt? Context windows are limited, costs explode, and the model gets distracted. Retrieval fetches only the 5 relevant chunks.

Step 1 — Extraction

Pull raw text out of PDFs, DOCX files, and web pages.

# pip install pypdf python-docx
from pypdf import PdfReader
from docx import Document

def extract_pdf(path: str) -> str:
    reader = PdfReader(path)
    return "\n".join(page.extract_text() for page in reader.pages)

def extract_docx(path: str) -> str:
    doc = Document(path)
    return "\n".join(p.text for p in doc.paragraphs if p.text.strip())

Simple explanation: extraction turns binary files into plain text. Always spot-check the output — scanned PDFs need OCR (pytesseract), and tables often come out garbled.

Step 2 — Chunking

LLMs and embedding models work best on small, self-contained pieces. Split documents into chunks of ~500–800 characters with slight overlap.

def chunk_text(text: str, size: int = 700, overlap: int = 100) -> list[str]:
    chunks = []
    start = 0
    while start < len(text):
        end = start + size
        chunk = text[start:end]
        # don't cut mid-sentence
        if end < len(text):
            last_period = chunk.rfind(". ")
            if last_period > size // 2:
                end = start + last_period + 1
                chunk = text[start:end]
        chunks.append(chunk.strip())
        start = end - overlap
    return chunks

Simple explanation: overlapping chunks mean a fact that straddles a boundary still appears fully inside at least one chunk. Ending on a sentence keeps each chunk readable on its own.

Best practice: store metadata with every chunk — source file, section title, last-updated date. You need it for citations and for re-indexing.

Step 3 — Embeddings

An embedding turns text into a vector (a list of numbers) where similar meanings sit close together in vector space.

import openai

def get_embedding(text: str) -> list[float]:
    response = openai.embeddings.create(
        model="text-embedding-3-small",
        input=text,
    )
    return response.data[0].embedding

Simple explanation: "How many vacation days do I get?" and "annual leave policy" end up with nearby vectors even though they share no keywords. That's why embeddings beat keyword search for this use case.

Step 4 — Storing in a Vector Database

A vector database stores embeddings and answers "which stored vectors are closest to this query vector?" fast.

# pip install chromadb
import chromadb

client = chromadb.PersistentClient(path="./kb_db")
collection = client.get_or_create_collection("company_docs")

def index_documents(docs: list[dict]):
    """docs = [{"id": ..., "text": ..., "metadata": {...}}]"""
    collection.add(
        ids=[d["id"] for d in docs],
        documents=[d["text"] for d in docs],
        metadatas=[d["metadata"] for d in docs],
    )

def search(query: str, k: int = 5):
    results = collection.query(query_texts=[query], n_results=k)
    return list(zip(results["documents"][0], results["metadatas"][0]))

Simple explanation: index_documents embeds and stores every chunk once (the ingestion pipeline). search embeds the question at runtime and returns the top-k most similar chunks with their metadata — which becomes your citation.

Note: when you don't pass embeddings explicitly, Chroma silently uses its own built-in embedding model — which ignores the OpenAI embeddings from Step 3 entirely. To use them, compute embeddings yourself and pass embeddings=[...] to both add() and query(), or configure a custom embedding_function. Whichever you choose, use one embedding model for both indexing and querying — mixing two models silently destroys search quality.

Options at different scales: Chroma or SQLite for prototypes, Pinecone/Weaviate/Qdrant for production, pgvector if the company already runs Postgres.

Step 5 — Retrieval-Augmented Generation

Now combine retrieval and generation into the assistant's answer flow.

def ask(question: str) -> str:
    chunks = search(question, k=5)
    context = "\n\n---\n\n".join(
        f"[Source: {meta['source']}]\n{text}" for text, meta in chunks
    )
    prompt = f"""Answer the question using ONLY the context below.
If the answer is not in the context, say "I couldn't find this in the company docs."
Cite the source name(s) you used.

Context:
{context}

Question: {question}
"""
    response = openai.chat.completions.create(
        model="gpt-4o-mini",
        messages=[{"role": "user", "content": prompt}],
        temperature=0.2,
    )
    return response.choices[0].message.content

Simple explanation: the retrieved chunks go into the prompt as the only allowed source of truth. The "I couldn't find this" rule prevents the model from filling gaps with plausible-sounding nonsense — the #1 failure mode of internal assistants.

Evaluating the Assistant

Build a test set of 50 real questions with known correct answers before launch. Then measure:

Practical improvement levers, in order of impact:

1. Fix the documents — rewrite vague policies with concrete answers.
2. Tune chunk size — try 400 vs 700 vs 1000 characters and re-run the test set.
3. Add metadata filters — for example, search only HR docs when the question mentions "leave".
4. Hybrid search — combine vector search with keyword search for product names and codes.

Keep the index fresh: re-run ingestion nightly on changed documents, or the assistant will confidently quote last year's policy — a worse failure than not answering at all.

Full Ingestion Pipeline

The code samples above are the pieces. Here is how they connect into one runnable pipeline with an index that tracks document versions.

# ingest.py — run nightly or on document change
import hashlib, chromadb
from sources import drive, confluence          # thin wrappers around each system
from processing import extract, chunk_text

client = chromadb.PersistentClient(path="./kb_db")
collection = client.get_or_create_collection("company_docs")
seen = load_seen_hashes()   # {source_path: content_hash}, persisted to seen_hashes.json

def content_hash(text: str) -> str:
    return hashlib.sha256(text.encode()).hexdigest()

def ingest_source(name: str, docs: list[dict]):
    """name = source label ("drive"/"confluence"); docs: [{"path", "text", "metadata"}]"""
    for doc in docs:
        h = content_hash(doc["text"])
        if seen.get(doc["path"]) == h:
            continue                            # unchanged — skip, saves cost

        # delete old chunks of this document, then re-add
        collection.delete(where={"source": doc["path"]})
        chunks = chunk_text(doc["text"])
        collection.add(
            ids=[f"{doc['path']}::{i}" for i in range(len(chunks))],
            documents=chunks,
            metadatas=[{**doc["metadata"], "source": doc["path"], "hash": h}
                       for _ in chunks],
        )
        seen[doc["path"]] = h

def main():
    # extract() picks extract_pdf / extract_docx by file extension (Step 1)
    ingest_source("drive", [extract(d) for d in drive.list_docs(folder="HR Policies")])
    ingest_source("confluence", [extract(d) for d in confluence.list_pages(space="ENG")])
    save_seen_hashes(seen)

if __name__ == "__main__":
    main()

Simple explanation: the content hash is the trick that makes nightly runs cheap — a document only gets re-chunked and re-embedded when its text actually changed. Deleting old chunks by source path before re-adding prevents the classic RAG bug where an updated policy and an outdated policy both live in the index, and the assistant answers with whichever chunk ranks higher.

The complete answer flow, with logging

# assistant.py — what the chat UI calls
import time, logging
from retrieval import search_for_user
from generation import build_prompt, call_llm

logger = logging.getLogger("assistant")

def ask(question: str, user: dict) -> dict:
    start = time.time()
    chunks = search_for_user(question, user, k=5)

    if not chunks:
        answer = "I couldn't find this in the company docs. Try rephrasing, or ask in #help."
        sources = []
    else:
        answer = call_llm(build_prompt(question, chunks))
        sources = [{"source": m.get("source", "unknown"), "title": m.get("title")} for _, m in chunks[:3]]

    logger.info("qa", extra={
        "user": user["id"], "question": question,
        "retrieved": [m.get("source", "unknown") for _, m in chunks],
        "latency_s": round(time.time() - start, 2),
    })
    return {"answer": answer, "sources": sources}

Simple explanation: every question is logged with what was retrieved and how long it took. After two weeks, that log is a goldmine: the questions that retrieved nothing tell you exactly which documents are missing or badly written — a prioritized to-do list for the doc owners.

Keeping the Index Fresh

An assistant quoting a deprecated policy destroys trust faster than never launching. Three mechanisms, in order of importance:

1. Nightly incremental sync (the pipeline above) — catches most changes.
2. Expiration metadata — documents with a review date get flagged:

from datetime import datetime

def is_stale(metadata: dict) -> bool:
    reviewed_on = metadata.get("last_reviewed")
    if not reviewed_on:
        return True                              # undated docs are untrustworthy
    age_days = (datetime.now() - datetime.fromisoformat(reviewed_on)).days
    return age_days > 365

Simple explanation: chunks from stale documents are either filtered out or labeled in the answer ("this policy hasn't been reviewed in over a year"). Forcing that conversation with doc owners is one of the most valuable side effects of the whole project — the company's documents get better because the assistant exposes them.

3. Ownership — each source folder has a named owner who gets a monthly email: "these 12 documents were marked stale, please review."

Handling Permissions and Confidential Docs

This is where RAG projects fail compliance review. The rule: filter at retrieval time, using the user's identity — never at the prompt level.

def search_for_user(query: str, user: dict, k: int = 5):
    allowed_teams = user["teams"]                # from your SSO/HR system
    results = collection.query(
        query_texts=[query],
        n_results=k,
        where={"visibility": {"$in": ["all_staff"] + allowed_teams}},
    )
    # same (text, metadata) pairs as the plain search() from Step 4
    return list(zip(results["documents"][0], results["metadatas"][0]))

Simple explanation: the vector DB filters on metadata before similarity ranking, so a restricted document's chunks are never even candidates. Trying to handle this in the prompt ("don't reveal salary info") is not security — the content already left the database.

Practical rules:

• Store visibility (e.g. all_staff, hr, finance, engineering) on every chunk at ingestion time.
• Personal documents (contracts, performance reviews) are excluded from the index entirely — no exceptions.
• Admins get an audit view: who asked what, and which sources were used. GDPR/SOC2 reviewers ask for this.

Project Timeline and Cost

A realistic 5-week timeline:

Estimated monthly running cost at 300 employees:

Simple explanation: RAG is one of the cheapest AI systems to run because the expensive part (embedding the corpus) happens once, and each question only pays for one retrieval plus one small LLM call. The real cost is human: keeping documents fresh.

Failure Modes and Fixes
